Main Feature
|
|
WAN
|
Cellular 2G/3G/4G LTE (FDD/TDD)
WiFi as WAN
Failover/Failback and Load
Balance (Bandwidth bonding)
Advanced Modem Failure Check
IP Passthrough
WAN ports support Cell/Static IP/DHCP/PPPoE (on demand,
keep alive, schedule, manual, standby)
|
|
LAN
|
DHCP Server, Client, Relay
DNS and DNS Proxy
DDNS
UPnP
DMZ
Multicast/Multicast Proxy
QoS (DSCP and Priority Queuing)
MAC Address Filtering
VLAN 802.1Q
|
|
WiFi
|
802.11 a/b/g/n
Up to 64 connected devices
WPA2 Enterprise (WiFi)
Hotspot/Captive Portal
SSID-based Priority
|
|
VPN AND ROUTING
|
IPsec Tunnel, PPTP, L2TP, GRE Tunnel, OpenVPN (option),
DMVPN (option);
OSPF/BGP/RIP, Virtual Server/Port Forwarding, IPv6
(option), VRRP;
|
|
MANAGEMENT
|
E-Lins Enterprise Cloud Network Management System (NMS)
Web UI, API, CLI/SSH/Telnet
Data Usage Alerts (router and per client)
Advanced Troubleshooting (support)
Device Alerts
SNMP
SMS control
TR-069
|
|
SECURITY
|
RADIUS and TACACS+ support
802.1x authentication for Ethernet
Certificate support
ALGs
MAC Address Filtering
Advanced Security Mode (local user management only)
Per-Client Web Filtering
IP Filtering
Content Filtering (basic)
Website Filtering
Zone-Based Object Firewall with host address (IP or
FQDN), port, and mac address
Other Details: NAT, SPI, port blocking, service
filtering (FTP, SMTP, HTTP, RPL, SNMP, DNS, ICMP, NNTP, POP3, SSH), protocol
filtering, WAN ping (allow/ignore)
|
|
OPTIMIZED IP COMMUNICATIONS
|
Automated WAN Failover/Failback support
WAN Affinity and QoS allow prioritization of VoIP
services
Advanced VPN connectivity options to HQ
SIP ALG and NAT to allow VoIP and UC communications to
traverse firewall
MAC Address Filtering
802.1p/q for LAN QoS segmentation and treatment of VoIP
on LAN
Private Network support (wired and 4G WAN)
|
|
Firmware update
|
support firmware update locally, remotely (LAN, WiFi
and OTA WAN) and NMS (Network Management System) option;
|
|
DI/DO (Digital Input and Output)
|
4 ports, 0-3.3V. Support status monitor via SMS and
Email;
Option: customers can order E-Lins switch control board
(5-40VDC supported)
|
|
Others
|
Cellular and WiFi MIMO supported;
Syslog (local and remote);
DDNS;
DNS proxy;
Optimized EMC design;
Real-time clock (NTP, support update with defined
hours);
WAN/LAN/Memory statistics;
Local/remote profiles backup and retrieve;
|
|
Feature
Details
|
|
Redundancy and Load Balancing
|
Failover/failback with 4G, 3G, 2G; WAN failure
detection, VRRP;
Auto-dial feature, keep alive link;
LCP, ICMP check;
Built-in watch dog;
Cellular (2G/3G/4G), RJ45 WAN (xDSL, DHCP, Fixed IP), WiFi client
three line redundancy;
Option Feature: Ethernet with rule selection, advanced
load balancing options (round robin, spillover, data usage, rate)
|
|
Intelligent Routing
|
UPnP, DMZ, virtual server/port forwarding, routing
rules, NAT-less routing, wired or wireless WAN-to-LAN IP passthrough, route
management, per-interface routing, content filtering, IP filtering, website
filtering, per-client Web filtering, local DHCP server, DHCP client, DHCP
relay, DNS, DNS proxy, Split DNS; ALGs: PPTP, SIP, TFTP, FTP, IRC; MAC
address filtering, Dynamic DNS, LAN/WAN affinity, VLAN 802.1Q (coming Q4),
STP, enterprise routing protocols: BGP/OSPF/RIP, multicast proxy support, IP
setting overrides, IPv6 support option;
|
|
Management
|
web-based GUI (local management), optional RADIUS or
TACACS+ username/password; remote WAN web-based management w/ access control
(HTTP, HTTPS); SNMP v1, v2c, & v3; CLI over SSH, SSH to serial, SSH to
telnet; API; one-button firmware upgrade; modem configuration, update, and management;
modem data usage w/ alerts, per-client data usage; custom AT scripting to
modems; SMS; TR-069;
Option: Enterprise Cloud Network Management System (NMS):
cloud-enabled management and application platform (subscription-based);
|
|
VPN
|
IPsec – Tunnel, NAT-T, and transport modes; connect to E-Lins,
Cradlepoint, Cisco/Linksys, CheckPoint, Watchguard, Juniper, SonicWall,
Adtran and others; Hash (MD5, SHA128, SHA256, SHA384, SHA512), Cipher (AES,
3DES, DES) , IPSec over L2TP support;
GRE tunneling;
PPTP support;
L2TP, L2TP over IPSec support;
VPN pass-through;
OpenVPN support (option);
DMVPN (option);
Certificate support (option);
multiple networks supported in a single tunnel,
site-to-site dynamic VPN with NHRP; VTI Tunnel support;
|
|
SMS, SMSControl and Alarm
|
Receive and Send the
SMS;
WAN Cell APN
configuration via SMS;
SMS/Voice Control and
Alarm. SMS or Call to control router to be online, offline, reboot, signal
and status monitor; SMS is default feature, Voice is option;
SMS text sending and receiving;
|
